7.25 Example — Tel 2M STL Image Slicer
PDF section 7.25. Source script: KrakenOS/Examples/Examp_Tel_2M-STL_ImageSlicer.py.
The most memory-hungry example in the library (~2 GB RAM): drops an STL-defined image slicer into the focal plane of the 2 m telescope and traces a dense ray fan to visualise the slicing action.
Figure 32. STL image slicer at the telescope focus.
# !/usr/bin/env python3
# -*- coding: utf-8 -*-
"""
Examp-2M-STL_ImageSlicer.py
"""
from importlib import metadata
""" Looking for if KrakenOS is installed, if not, it assumes that
an folder downloaded from github is run"""
required = {'KrakenOS'}
installed = {dist.metadata["Name"] for dist in metadata.distributions() if dist.metadata.get("Name")}
missing = {pkg for pkg in required if pkg not in installed}
if missing:
print("Not installed")
import sys
sys.path.append("../..")
import KrakenOS as Kos
import numpy as np
import matplotlib.pyplot as plt
import scipy
import os
A1 = 1
if A1 == 0:
# _________________________________________________________________#
P_Obj = Kos.surf()
P_Obj.Rc = 0
P_Obj.Thickness = 1000 + 3.452200000000000E+003
P_Obj.Glass = "AIR"
P_Obj.Diameter = 1.059E+003 * 2.0
# _________________________________________________________________#
Thickness = 3.452200000000000E+003
M1 = Kos.surf()
M1.Rc = -9.638000000004009E+003
M1.Thickness = -Thickness
M1.k = -1.077310000000000E+000
M1.Glass = "MIRROR"
M1.Diameter = 1.059E+003 * 2.0
M1.InDiameter = 250 * 2.0
# _________________________________________________________________#
M2 = Kos.surf()
M2.Rc = -3.93E+003
M2.Thickness = Thickness + 1.037525880125084E+003
M2.k = -4.328100000000000E+000
M2.Glass = "MIRROR"
M2.Diameter = 3.365E+002 * 2.0
M2.AxisMove = 0
# _________________________________________________________________#
P_Image_A = Kos.surf()
P_Image_A.Diameter = 10.0
P_Image_A.Glass = "AIR"
P_Image_A.Thickness = 10
P_Image_A.Name = "Image plane Tel"
P_Image_A.DespZ = -100.0
# _________________________________________________________________#
A = [P_Obj, M1, M2, P_Image_A]
# _________________________________________________________________#
configuracion_1 = Kos.Setup()
Telescopio = Kos.system(A, configuracion_1)
Rayos = Kos.raykeeper(Telescopio)
# _________________________________________________________________#
# Gaussian
def f(x):
x = np.rad2deg(x)
seing = 2 * 1.2 / 3600.0
sigma = seing / 2.3548
mean = 0
standard_deviation = sigma
y = scipy.stats.norm(mean, standard_deviation)
res = y.pdf(x)
return res
Sun = Kos.SourceRnd()
Sun.field = 4 * 1.2 / (2.0 * 3600.0)
Sun.fun = f
Sun.dim = 2100
Sun.num = 300000
L, M, N, X, Y, Z = Sun.rays()
Xr = []
Yr = []
Zr = []
Lr = []
Mr = []
Nr = []
W = 0.6
for i in range(0, Sun.num):
pSource_0 = [X[i], Y[i], Z[i]]
dCos = [L[i], M[i], N[i]]
Telescopio.Trace(pSource_0, dCos, W)
print(Telescopio.NAME[-1])
if Telescopio.NAME[-1] == "Image plane Tel":
x, y, z = Telescopio.XYZ[-1]
l, m, n = Telescopio.LMN[-1]
Xr.append(x)
Yr.append(y)
Zr.append(z)
Lr.append(l)
Mr.append(m)
Nr.append(n)
Xr = np.asarray(Xr)
Yr = np.asarray(Yr)
Zr = np.asarray(Zr)
Lr = np.asarray(Lr)
Mr = np.asarray(Mr)
Nr = np.asarray(Nr)
W = W * np.ones_like(Nr)
Rays = np.vstack((Xr, Yr, Zr, Lr, Mr, Nr, W))
outfile = "savedRays.npy"
np.save(outfile, Rays)
################################################################
else:
P_Obj = Kos.surf()
P_Obj.Rc = 0
P_Obj.Thickness = 100. + 0.5
P_Obj.Glass = "AIR"
P_Obj.Diameter = 10
# currentDirectory = os.getcwd()
ruta = os.getcwd()
import os.path
ruta = ruta + "/Jherrera-ImageSlicerBW-00.stl"
existe = os.path.exists(ruta)
if existe:
print("El archivo existe.")
else:
print("El archivo no existe.")
direc = ruta
P_ImageSlicer = Kos.surf()
P_ImageSlicer.Diameter = 10.0
P_ImageSlicer.Glass = "BK7"
P_ImageSlicer.Name = "Image slicer"
P_ImageSlicer.Solid_3d_stl = direc
P_ImageSlicer.Thickness = 100
P_ImageSlicer.TiltX = 180.0
P_ImageSlicer.DespX = -0.55
P_ImageSlicer.DespY = -0.12
P_ImageSlicer.AxisMove = 0
PerfLen = Kos.surf()
PerfLen.Diameter = 30.0
PerfLen.Thin_Lens = 50
PerfLen.Thickness = 100+10-7.19
P_Ima = Kos.surf()
P_Ima.Diameter = 10.0
P_Ima.Glass = "AIR"
P_Ima.Name = "Plano imagen"
# _________________________________________________________________#
A = [P_Obj, P_ImageSlicer, PerfLen, P_Ima]
configuracion_1 = Kos.Setup()
ImageSlicer = Kos.system(A, configuracion_1)
Rayos = Kos.raykeeper(ImageSlicer)
outfile = "savedRays.npy"
R = np.load(outfile)
print(np.shape(R))
X, Y, Z, L, M, N, W = R[0, :], R[1, :], R[2, :], R[3, :], R[4, :], R[5, :], R[6, :]
nrays = 2000
Xr = np.zeros(nrays)
Yr = np.zeros(nrays)
Zr = np.zeros(nrays)
Lr = np.zeros(nrays)
Mr = np.zeros(nrays)
Nr = np.zeros(nrays)
NM = np.zeros(nrays)
con = 0
con2 = 0
for i in range(0, nrays):
if con2 == 10:
print(100. * i / nrays)
con2 = 0
pSource_0 = [X[i], Y[i], Z[i] * 0]
dCos = [L[i], M[i], N[i]]
ImageSlicer.NsTrace(pSource_0, dCos, W[i])
x, y, z = ImageSlicer.XYZ[-1]
l, m, n = ImageSlicer.LMN[-1]
Xr[con] = x
Yr[con] = y
Zr[con] = z
Lr[con] = l
Mr[con] = m
Nr[con] = n
AA = ImageSlicer.SURFACE
AA = np.asarray(AA)
AW = np.argwhere(AA == 1)
if ImageSlicer.NAME[-1] == "Plano imagen" and len(AW) < 10 and ImageSlicer.TT < 0.9:
# and ImageSlicer.TT<0.9 and ImageSlicer.TT>0.4
NM[con] = i
Rayos.push()
else:
NM[con] = -1
con = con + 1
con2 = con2 + 1
args = np.argwhere(NM != -1)
X = Xr[args]
Y = Yr[args]
Z = Zr[args]
L = Lr[args]
M = Mr[args]
N = Nr[args]
W = W * np.ones_like(N)
###################
plt.plot(X, Y, '.', c="r", markersize=1)
# axis labeling
plt.xlabel('x')
plt.ylabel('y')
# figure name
plt.title('Dot Plot')
plt.axis('square')
plt.show()
# Rays.push()
Kos.display3d(ImageSlicer, Rayos, 0)
